RG Flex® Telecom Power Cable

Cablcon (formerly Jupiter Communications) exclusively offers RG Flex® cables, a family of DC Power Cables that have been tested and certified by Telcordia and meet the functional performance requirements of GR-347 Issue 3, TPR.9212 and ATIS-0600017.2020. RG Flex cables, also known as Central Office Power Cables, are Telcordia-certified meaning that the L2, L3, and L4 power cables are suitable for use in all telecommunications applications including central offices, remote terminal applications, data center and outside plant remote cabinets that house electronics equipment.

Distinguishing L2, L3, and L4 Cables

These cable types differ in lay method and presence of a braid. L2 and L4 (Class I) use rope lay, enhancing flexibility and strength. L3 (Class B) employs conventional helical stranding for cost efficiency, with fewer, thicker strands. L3 and L4 have a flame-retardant cotton braid for fire resistance, while L2 lacks a braid in models like TelcoFlex II and EcoSafe CO II.

L2 Telecom Power Cable

  • Flexible Class I Strand
  • No Braid
  • Nonflammable Smooth Coated Jacket
  • Tinned Copper Conductor 600 Volt
  • Low Smoke Zero Halogen "LSZH"

L3 Telecom Power Cable

  • Non-Flexible Class B Strand
  • Braided
  • Tinned Copper Conductor 600 Volt
  • Low Smoke Zero Halogen "LSZH"

L4 Telecom Power Cable

  • Flexible Class I Strand
  • Braided
  • Tinned Copper Conductor 600 Volt
  • Low Smoke Zero Halogen "LSZH"

Telecom Power Cable

IEWC knows that in order for the telecom infrastructure to remain sound, engineers and procurement specialists must source high quality materials that meet all the necessary industry specifications and also ensure a specifications entire list of components is available for technicians. IEWC exclusively offers RG Flex® telecom DC Power cables. Paired up with Burndy connectors and installed with Burndy tooling, you have an engineered system and proven winning connection.

Tested to Meet The Following Standards

  • Telcordia GR-347-CORE 13
  • ATIS 06000017.2020
  • KS24194
  • VZ.TPR.9212
  • UL Listed

Installation Kits

  • Pre-Formed Installation Kits - Cabinet & Shelter, Jumpers & Pigtails
  • Reduces Total Installation Cost (TIC) & Total Cost of Ownership (TCO)

Value-Add Services

  • Cable Cutting
  • Custom Packing & Labeling
  • Tracer Capabilities
  • Custom Cut, Strip, and Terminating Capabilities
  • Kitting
  • Cablcon Web Based Fiber Optic Test Report

Associated Products

  • Lugs
  • Heat Shrink
  • Bus Bar
  • Fish Paper
  • P-tags
  • Lacing Cord
  • Fuses
  • Breakers
  • "PDU" Power Distribution Unit
  • Contact Us To Learn More

    • Industries We Serve

    List 2 DC Power Cable - Available Cable Constructions

    Size
    AWG or kcmil

    Stranding
    Number/dia (inch)

    Conductor
    diameter (inches)

    Insulation min.
    Thickness (mils)

    Nominal insulation
    Diameter (inches)

    Max.d.c.res. @ 20°C
    (ohms/ mft.)

    Approx. Weight
    lbs./mft.

    167/0.01970.059300.1184.8115
    1441/0.01000.074450.1812.72825.4
    1265/0.01000.093450.1971.71934.8
    10105/0.01000.12450.2281.07950
    841/0.02010.147600.280.6877.8
    665/0.02010.192600.3190.436112.6
    4105/0.02010.257600.3940.274169.4
    2165/0.02010.309600.4450.172248.5
    1/0266/0.02010.398800.5750.109405.2
    2/0342/0.02010.455800.630.087516.5
    4/0532/0.02010.571800.7480.055754.9
    350882/0.02010.752950.9650.0341194.1
    5001221/0.02010.894951.1020.0231606.5
    7501850/0.02011.0671101.3230.016

    2414.4

    View spec sheet as a PDF

    List 3 DC Power Cable - Available Cable Constructions

    Size
    AWG or kcmil

    Stranding
    Number/dia (inch)

    Conductor
    diameter (inches)

    Insulation min.
    Thickness (mils)

    Nominal insulation
    Diameter (inches)

    Nominal braid
    diameter (inches)

    Max.d.c.res. @ 20°C
    (ohms/ mft.)

    Approx. Weight
    lbs./mft.

    147/0.02400.071450.1730.242.73133.6
    127/0.03030.09450.1930.2561.71948.6
    107/0.03860.113450.2170.2791.07964.1
    87/0.04840.143600.2760.3380.67797.1
    67/0.06100.181600.310.3780.427127.6
    47/0.07720.228600.3580.4250.268189.8
    27/0.09720.286600.4170.4840.169272.6
    1/019/0.07440.366800.5390.610.106432
    2/019/0.08390.417800.5870.6610.084534.4
    4/019/0.10550.524800.6930.7710.052794.4
    35037/0.09720.665950.870.9410.0321258
    50037/0.11420.803951.0081.0780.0211769.8
    75061/0.11100.9761101.2131.2830.0152574.6

    View spec sheet as a PDF

    List 4 DC Power Cable - Available Cable Constructions

    Size
    AWG or kcmil

    Stranding
    Number/dia (inch)

    Conductor
    diameter (inches)

    Insulation min.
    Thickness (mils)

    Nominal insulation
    Diameter (inches)

    Nominal braid
    diameter (inches)

    Max.d.c.res. @ 20°C
    (ohms/ mft.)

    Approx. Weight
    lbs./mft.

    841/0.02010.147600.280.3420.6898.1
    665/0.02010.192600.3150.3810.436135.3
    4105/0.02010.257600.390.4520.274195.5
    2165/0.02010.309600.4410.5080.172278.5
    1/0266/0.02010.398800.5710.6410.109442.8
    2/0342/0.02010.455800.6260.70.087548.1
    4/0532/0.02010.571800.7360.8140.055804.1
    350882/0.02010.752950.9531.0270.0341254.9
    5001221/0.02010.894951.0871.1570.0231676
    7501850/0.02011.0671101.3071.3820.0162499.6

    View spec sheet as PDF

    Cablcon (formerly Jupiter Communications) is the exclusive distributor for all RG Flex® power cables in North America.
